Data sheet
Fernsteuerung für Kugel-hahn mit Timerfunktion
{{ $t('shop.all.artikelnummer') }}:
KH TIME REMOTE
Example illustration
{{ $t('shop.display.artikel.beschreibung_headline') }}
Materials:
Body ball valve: nickel-plated brass, ball: stainless steel, seal: PTFE, drive housing: plastic
Temperature range:
+1 to +50 °C (medium: +1 to +100 °C
Media:
Compressed air and other neutral media
Power supply:
230 V (AC) (clock and program are battery buffered)
Protection class:
IP 54
Programming:
accurate to the minute, up to 16 switching cycles per day, each weekday individually programmable
Operation:
using timers (automatic), manual operation (timer switch) or manual operation (e.g. power failure). With ceiling installation, we recommend the use of remote controls.
Advantages:
•energy savings by automatically closing the compressed air line after work and automatically opening it before work starts
Warning:
In case of high media temperatures, the actuator must be cooled if necessary!
{{ $t('shop.display.artikel.eigenschaften_headline') }}
| Version | Remote control with 5 m. cable |
Further information:
| {{ $t('shop.all.gewicht') }} | 470 g / pcs |
| {{ $t('shop.all.gtin') }} | 4050571427757 |
| {{ $t('shop.display.artikel.zollwarennummer') }} | 84818081 |
| {{ $t('shop.display.artikel.rohskonform') }} | {{ $t('shop.all.ja') }} |
Figure
More information on this item and the process for ordering it can be found in our online shop https://www.landefeld.de under item number KH TIME REMOTE.
Landefeld Druckluft und Hydraulik GmbH · Konrad-Zuse-Straße 1 · 34123 Kassel · Germany
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
Our products arid goods are generally only intended for industrial and commercial uses.
Our products arid goods are generally only intended for industrial and commercial uses.
As of: 13.12.2025
