Data sheet
DYSS-G8-8-8-Y1F (8073916) Shock absorber
{{ $t('shop.all.artikelnummer') }}:
OT-FESTO081407
Example illustration
{{ $t('shop.display.artikel.eigenschaften_headline') }}
| size | 20 |
| Stroke [mm] | 8 |
| Dampening | self-adjusting |
| installation position | arbitrary |
| Position detection | without |
| Max. impact speed [m/s] | 1,5 |
| Rest time short [s] | 0,2 |
| Reset time at room temperature [s] | 1 |
| Reset time at min. ambient temperature |
Pressing, single action |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -10 to 80 |
| LABS (PWIS) conformity [mm] | 8 |
| Max. impact force [N] | 500 |
| Max. tightening torque [Nm] | 5,0 |
| Max. energy consumption per stroke [J] | 3,0 |
| Max. energy consumption per hour [J] | 18.000 |
| Max. residual energy [J] | 0,020 |
| Reset force [N] | 2,5 |
| Fastening type | With Threaded sleeve |
| Min. insertion force | RoHs compliant |
| Seals material | NBR |
| Housing material | High-alloyed steel |
| Piston rod material | High-alloyed steel |
Further information:
| {{ $t('shop.all.gewicht') }} | 60 g / pcs |
| {{ $t('shop.all.gtin') }} | 4052568446161 |
| {{ $t('shop.display.artikel.zollwarennummer') }} | 84879059 |
| {{ $t('shop.all.hersteller') }} | Festo |
Figure
