Data sheet
Control panel installation set for throttle & throttle check valve
{{ $t('shop.all.artikelnummer') }}:
DV EINBAUSET 1438
Example illustration
{{ $t('shop.display.artikel.beschreibung_headline') }}
Application:
Bidirectional flow control valves and one way flow control valves influence the volume flow rate via an adjustable cross section constriction and are used to adjust the speed of cylinders or motors.
Materials:
valve body: zinc-plated steel, rotary knob: polyamide, seals: NBR
Temperature range:
-20 to +80 °C
Operating pressure:
max. 350 bar
Media:
Hydraulic oils on the basis of mineral oil
{{ $t('shop.display.artikel.eigenschaften_headline') }}
| Version | Control panel installation set for throttle & throttle check valve |
Further information:
| {{ $t('shop.all.gewicht') }} | 35 g / pcs |
| {{ $t('shop.all.gtin') }} | 4050571277246 |
| {{ $t('shop.display.artikel.zollwarennummer') }} | 84812010 |
| {{ $t('shop.all.hersteller') }} | Hydac |
Figure
Drawing:
Drawing: Throttle valve / throttle check valve
More information on this item and the process for ordering it can be found in our online shop https://www.landefeld.de under item number DV EINBAUSET 1438.
