Pressure regulator G 1/4", 0,2 to 6 bar, model series Standard 1

Name: Pressure regulator G 1/4", 0,2 to 6 bar, model series Standard 1
Brand: Landefeld
SKU: DR 11-6
Price: 65.22 EUR
Availability: InStock

Item number:

DR 11-6

All items of this group

Pohled 360 stupnu: DR 11-6 - Tlakový regulátor G 1/4", 0,2 az 6 bar, konstrukcní rad Standard 1

€65.22 incl. VAT

Quantity

pcs

Immediately available from the warehouse; order by 16:30 and we will send it today.

Item description

Version:
Self-relieving pressure regulator

Materials:
Body: die-cast zinc Z410 (model series 5 and 7: aluminium), diaphragms and seals: NBR

Temperature range:
-10 to +60 °C

Pressure gauge connection:
G 1/4"

Switch panel thread:
Series 1 to 3: M 20x1.5

Media:
Compressed air, neutral gases

Scope of delivery:
Pressure regulator incl. 50 mm pressure gauge

ATEX:
Operating material without its own potential source of ignition in accordance with Directive 2014/34/EU

Optional:
Other pressure regulation ranges: 0.1-3 bar -3, 0.2-6 bar -6, 0.5-16 bar -16

Advantages:
•Automatic venting in the event of overpressure on the secondary side

Properties

Model series	Standard 1
Thread	G 1/4"
Pressure regulation range [bar]	0,2 - 6
flow [l/min]	1000
input pressure [bar]	max. 16
Pressure gauge display [bar]	0 - 10
H [mm]	132
H1 [mm]	32
L [mm]	54
Mounting brackets	BW 10

Further information on DR11-6

Weight	550 g / pcs
GTIN	4050571264994
Customs duty number	84811099
RoHS compliant	Yes

YouTube videos:

Regulátor tlaku - standardní vs. presnost!

Documents

Catalogue page Atlas 9 (Page 602) (PDF)
Documentation (PDF)
Documentation: Decision aid for selection of air units (PDF)
3D CAD file (volume model) (Only for customers that are logged in) (STP)
Data sheet (Print view)

All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
