Opis artikla
Materials:
Body: nickel-plated brass / PBT, sleeve: POM, seal: NBR, holding claws: stainless steel, cartridge: nickel-plated ZnDC
Temperature range:
-20 do +60 °C
Operating pressure:
-0,95 do 10 bar
Media:
oiled and unoiled compressed air, neutral gases and water (water up to max 60° C may be used only after we have approved the performance specifications).
Advantages:
•Wide variety of products,
•extremely tight due to lip seal,
•available with conical, PTFE-coated thread or with cylindrical thread and captive O-ring
Note:
For assembling, please order o-rings separately!
Body: nickel-plated brass / PBT, sleeve: POM, seal: NBR, holding claws: stainless steel, cartridge: nickel-plated ZnDC
Temperature range:
-20 do +60 °C
Operating pressure:
-0,95 do 10 bar
Media:
oiled and unoiled compressed air, neutral gases and water (water up to max 60° C may be used only after we have approved the performance specifications).
Advantages:
•Wide variety of products,
•extremely tight due to lip seal,
•available with conical, PTFE-coated thread or with cylindrical thread and captive O-ring
Note:
For assembling, please order o-rings separately!
Lastnosti
| G | G 1/4" |
| D | 10 |
| Tesnilni obroči | IQSVOR 14 |
Dodatne informacije o IQSVTK1410
| Teža | 17 g / Kos |
| GTIN | 4050571387938 |
| Številka carinskega blaga | 39174000 |
| Proizvajalec | Sang-A |
Dokumenti
- Catalogue page Atlas 9 (Page 51) (PDF)
- Dokumentacijo: Decision-making tool for the selection of IQS push in fittings and the matching hoses (PDF)
- 3D CAD file (volume model) (Samo za prijavljene stranke) (STP)
- Podatkovni list (Pogled za tiskanje)
- Podatkovni list (angleščina) (Pogled za tiskanje)
*Operating pressure: 10 bar, 60°C max., plastic body made of PBT
Vse navedbe podatkov so nezavezujoče orientacijske vrednosti! Za izbiro podatkov, za katere ne izdamo pisnega potrdila, ne prevzemamo jamstev. Navedbe tlaka, v kolikor ni navedeno drugače, se nanašajo na tekočine skupine II. pri +20°C.
