Operating voltage range DC [V] | 0 to 250 |
Operating voltage range AC [V] | 0 to 250 |
Current carrying capacity at 40°C [A] | 6 |
Cable screwing | M16x1,5 |
Cable diameter [mm] | 6 to 8 |
Protection category | IP65 |
ambient temperature [°C] | -20 to 115 |
Degree of contamination | 3 |
Housing material | PA reinforced |
Housing colour | black |
Seals material | HNBR |
Surge voltage strength [kV] | 2,0 |
Conductor - nominal cross-section [mm²] | <= 0,75 mm2 |
Material information | RoHs compliant |
Corrosion resistant class KBK | 1 - low corrosion stress |
Connection frequency | 50 |
Cable output | Angled |
Information about cable outlet | Can be moved by 180° |
Electrical connection 1, design | Angular |
Electrical connection 1, connection type | socket / container / …. |
Electrical connection 1, connection technology | Wiring diagram Form B acc. to industry standard 11 mm |
Electrical connection 1, number of pins / wires | 3 |
Electrical connection 1, fastening type | on solenoid valve with central screw M3 |
Electrical connection 2, connection technology | Screw clamp |
Protection line connection | Available |
Information about protection category | In mounted condition |
hmotnost | 22 g / ks |
GTIN | 4052568050047 |
Celní číslo zboží | 85366990 |
výrobce | Festo |
