Egenskaber
| Valve function | Throttle blowback function |
| Pneumatic connection 1 | G3/8 |
| Pneumatic connection 2 | G3/8 |
| Setting element | slotted screw |
| Fastening type | Screwable |
| Normal nominal flow in one-way flow control [l/min] | 1450 |
| Normal nominal flow in check valve direction [l/min] | 970 to 1600 |
| Operating pressure [bar] | 0.3 to 10 |
| ambient temperature [°C] | -20 to 80 |
| Maritime classification | see Certificate |
| installation position | arbitrary |
| Normal flow In one-way flow control 6 -> 0 bar [l/min] | 2515 |
| Normal flow In check valve direction 6 -> 0 bar [l/min] | 2095 to 2665 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Medium temperature [°C] | -10 to 60 |
| Nominal width [mm] | 8,5 |
| Max. tightening torque [Nm] | 20,0 |
| Material information | RoHs compliant |
| Seals material |
FKM, PVC |
| Regulation screw material | High-alloyed stainless steels |
| Swivel connection material | High-alloyed stainless steels |
| Banjo bolt material | High-alloyed steel |
| Bearing temperature [°C] | -10 to 40 |
| Food compatibility | See expanded material information |
| Permitted actuation moment regulation disc [Nm] | 2,0 |
Yderligere oplysninger om OT-FESTO011749
| Vægt | 130 g / styk |
| GTIN | 4052568129200 |
| Toldvarenummer | 84812090 |
| Producent | Festo |
Dokumenter
- Dokumentation (english) (PDF)
- Gruppedatablad: GRX-VFO (english) (PDF)
- Datablad (Udskriftsvisning)
- Datablad (engelsk) (Udskriftsvisning)
Samtlige oplysninger er vejledende! Vi påtager os intet ansvar for oplysninger, der ikke er skriftligt bekræftede. Medmindre andet fremgår, er trykoplysninger for væsker gruppe II gældende ved +20 °C.
